Greenlee DigiVolt Digital Voltmeter 80kV DVM-80UVM

Greenlee

DigiVolt Digital Voltmeter 80kV DVM-80UVM

FEATURES:

• Measures voltage and performs phasing operations from 50V to 40kV and up to 80kV with add-on resistors
• Provides consistent high accuracy voltage measurements – within 1% of reading
• Auto-ranging – no settings required
• Capacitive Test Point and Peak Hold modes
• Auto-shutoff and low battery indicator features
• Versatile for overhead and underground applications

SPECIFICATIONS:

Sub Brand	HDE
Type	Voltmeter
Model	DVM-80UVM
Voltage Rating	5V – 40kV up to 80kV with add-on resistors
Accuracy	Within 1% of reading +/- 3 counts (line-to-ground and line-to-line measurements); Within 2% of reading +/- 3 counts (line-to-ground & line-to-line measurements) with add-on resistors
Display	LCD indicates 3.5 digits
Operating Temperature	-20°F to +140°F (–29°C to +60°C)
Dimensions	5 W x 4.25″ L x 1.38″ H (13 cm x 11 cm x 3.5 cm)
Frequency Rating	25 – 1000Hz AC/DC
Included	DVM-80UVM Voltmeter; 025-OLPS-5 Overhead Brass Hook Probes (2); CS-DVM Case

“
